2. Commissioning
2-13
Festo P.BE-CPX-PNIO-EN en 1407c English
Pneumatic interface for MPA/
MPA-F and related modul es
Module type Module
indicator
1)
Allocated address
space
(Name) Inputs Outputs
VPPM proportional-pressure regu-
lation valve (type 32; 2 bar, 6 bar,
10 bar, “not equipped” or vacant
position)
2) 3)
VPPM-6...-1-...
[2AI/2AO]
VPPM
Proportional
valve ...
1word/
16 I
1word/
16 O
MPA-P Pre ssure sensor module
2) 3)
(measuring range 0 ... 10 bar)
VMPA...-FB-PS-...
[2AI-P]
MPA-P
Analogue in-
put press.
1word/
16 I
–
MPAF-P pneumatic interface with
pressure sensor
2) 3) 4)
Measurement range 0 ... 10 bar)
VMPAF-FB-EPL-PS
[1AI-P]
MPAF-P
Analogue in-
put press.
1word/
16 I
–
1)
Modu l e iden ti fier in the operator un it or in the hardware confi gu rati on of the programmi n g software
2
) No support for the additional func tion FSU
Note
When using the module in FSU operation, fast running up of the CPX terminal and compliance of
the PROF IN ET specification with regard to FSU are not guaranteed.
3)
Pneumatic modules of type MPA-P or MPAF-P and VPPM are among the analogue modules:
Observe the sequence of the modules as part of addressing or in I/O mapping (see Tab. 2/9)
4)
MPAF-P is also called “end plat e” with pressure sensor or pressure sensor plate
Tab. 2/6: Overview of CPX pneumatic interfaces and pneumatic modules (part 2)
