2. Commissioning
2-12
Festo P.BE-CPX-PNIO-E N en 1407c English
Pneumatic interface for MPA/
MPA-F and related modul es
Module type
(Designation of the
electronic module)
Module
indicator
1)
Allocated address
space
Inputs Outputs
Pneumatic interface for M PA or
MPA-F valves (type 32/33)
VMPA -FB-EPL-... – – –
MPA1 pneumatic module
(type 32, 33): 1-8V..)
without galvanic isolation
VMPA1-FB-EMS-8
[8DO]
MPA1S
Valve module
– 1byte/
8O
MPA1 pneumatic module
(type 32, 33: 1-8V..)
with galvanic isolation
VMPA1-FB-EMG-8
[8DO]
MPA1G
Valve module
– 1byte/
8O
MPA2 pneumatic module
(type 32/33): 1-4V..)
without galvanic isolation
VMPA2-FB-EMS-4
[4DO]
MPA2S
Valve module
– 1byte/
4(8)O
2)
MPA2 pneumatic module
(type 32, 33: 1-4V..)
with galvanic isolation
VMPA2-FB-EMG-4
[4DO]
MPA2G
Valve module
– 1byte/
4(8)O
2)
MPA1 pneumatic module
(type 32, 33): 1-8V..)
without galvanic isolation,
with diag nost ic function D2
VMPA1-FB-EMS-
D2-8
[8DO]
MPA1S-D
Valve module
– 1byte/
8O
MPA1 pneumatic module
(type 32, 33: 1-8V..)
with galvanic isolation,
with diag nost ic function D2
VMPA1-FB-EMG-
D2-8
[8DO]
MPA1G-D
Valve module
– 1byte/
8O
MPA2 pneumatic module
(type 32/33): 1-4V..)
without galvanic isolation,
with diag nost ic function D2
VMPA2-FB-EMS-
D2-4
[4DO]
MPA2S-D
Valve module
– 1byte/
4(8)O
2)
MPA2 pneumatic module
(type 32, 33: 1-4V..)
with galvanic isolation,
with diag nost ic function D2
VMPA2-FB-EMG-
D2-4
[4DO]
MPA2G-D
Valve module
– 1byte/
4(8)O
2)
1)
Modu l e iden ti fier in the operator un it or in the hardware confi gu rati on of the programmi n g software
2)
4-off modules MPA2 always occupy 8 O (1 byte) of address space (4 O or 8 bits remain unused)
Tab. 2/5: Overview of CPX pneumatic interfaces and pneumatic modules (part 1)
