The configuratio n table represents your CPX terminal.
This area of the HW Config window as well as the higher- l evel
graphic representation is also designated as the Rack Rail
window. In the documentation for your control system, the
designation profile rail, mounting rack, or rail may be found
instead of “rack rail”.
Open station symbol 5. In the hardware catalogue, open the station symbol
( 3 ) co rrespondi ng to your appli cation and the related
field device groups (“Bus node and module folder”, 4
in Fig. 2/11).
Note
Open the same station symbol as with the station selectio n
in section 2.6.2.
Select and insert bus
node, inser t modules
6. Pull the required catalogue elements, i.e. first the bus
node and then the modules of your CPX terminal corres-
ponding to the “physical” sequence (as mounted, from
left to right) into the co nfiguration table.
Note
Various catalogue elements are avail able for linking the
bus node: Observe the subsequent sections.
Choose the required bus node catalogue element based
on the follow i ng Tab. 2/12 – dependent on:
– operating mode of the bus node
(see section 1.4.2 or Tab. 1/1)
– Diagnostic mode of the bus node
(see section 1.4.2 or Tab. 1/3)
