SOPA-…
-C
-M-2P/-2N -M-PNLK
Rated operating
voltage
[V DC] 24
Operating voltage [V DC] 22.8…26.4 15.0…30.0 20.0…30.0
No-load supply current [mA] £ 10 £ 50
Reverse polarity pro-
tection
For all electrical connections
Tab. 45 Electronics
SOPA-…
Connection type Plug
Connection technology M12x1 A-coded
Number of pins/wires 5
Tightening torque [Nm] 0.3
Cable length [m] £ 30
[m] £ 20 (for IO-Link)
Tab. 46 Electromechanics
SOPA-… -C -M
Mounting position any
1)
Nominal diameter of
measuring nozzle
[mm] 2
Specified measuring
nozzle diameter
[mm] 1.5/2/2.5
Pneumatic port QS-6
Tube length [m] 0.5…8
1) condensate must not collect in the sensor module.
Tab. 47 Mechanics
SOPA-… -C -M
Housing Reinforced PA/anodised alu-
minium
PA-reinforced
Keypad PET PA6
Inspection window
–
PA
Sealing ring HNBR, NBR HNBR, FPM, NBR
Technical data
52 Festo — SOPA — 2020-04
