FISCHER FT90 - Page 100

7 | Technical data FISCHER Mess- und Regeltechnik GmbH
100/108 BA_EN_FT90
Mounting rail
9811
11
9
35
38.5
4.5
5
19
5
4.5
Fig.143: Mounting rail
Process connection
Cutting ring
screw connection
CK gland Pneumatic-
plug connection
12
G⅛G⅛
L
D
G⅛
D
L
D
G⅛
AF3
AF1 AF1
AF2
AF2
AF2
Union nutUnion nut
Cutting ring
Screw connection
removable disk
Screw connection
removable disk
12
G⅛
AF1
Screw connection
removable disk
L
Fig.144: Options for the process connection
Process connection D d L SW1 SW2 SW3
Cutting ring screw connection Pipe 6 --- 23.5 14 14 14
8 --- 24.5 14 17 14
CK screw connection Hose 6 4 21 14 12 ---
8 6 21 14 14 ---
Pneumatic plug-in connection Pneumatic
hose
6 4 18 14 11 ---
8 6 20.5 14 13 ---
D: Outer diameter; d: Inner diameter
