Symmetric measuring ranges:
Measuring range Overload Bursting
pressure
Sensor
-25 to +25 Pa 750 mbar 1 bar A
-40 to +40 Pa 750 mbar 1 bar A
-60 to +60 Pa 750 mbar 1 bar A
-1 to +1 mbar -100 to +100 Pa 750 mbar 1 bar A
-1.6 to +1.6 mbar -160 to +160 Pa 750 mbar 1 bar A
-2.5 to +2.5 mbar -250 to +250 Pa 100 mbar 200 mbar B
-2.5 to +2.5 mbar -250 to +250 Pa 750 mbar 1 bar A *
-4 to +4 mbar -400 to +400 Pa 100 mbar 200 mbar B
-4 to +4 mbar -400 to +400 Pa 750 mbar 1 bar A *
-6 to +6 mbar -600 to +600 Pa 100 mbar 200 mbar B
-6 to +6 mbar -600 to +600 Pa 750 mbar 1 bar A *
-10 to +10 mbar -1 to +1 kPa 100 mbar 200 mbar B
-10 to +10 mbar -1 to +1 kPa 750 mbar 1 bar A *
-16 to +16 mbar -1.6 to +1.6 kPa 400 mbar 800 mbar B
-25 to +25 mbar -2.5 to +2.5 kPa 400 mbar 800 mbar B
-40 to +40 mbar -4 to +4 kPa 400 mbar 800 mbar B
-60 to +60 mbar -6 to +6 kPa 1 bar 2 bar B
-100 to +100 mbar -10 to +10 kPa 1 bar 2 bar B
-160 to +160 mbar -16 to +16 kPa 2.5 bar 5 bar B
-250 to +250 mbar -25 to +25 kPa 2.5 bar 5 bar B
*)
Measuring range with increased overload and bursting pressure capability
(see 'Order codes/Special aspects')
7.3 Output sizes
Analog outputs
The number of analogue outputs depends on the device version.
Device version Temperature
Humidity
Temperature
Humidity
Differential pres-
sure
Number of analog outputs 2 3
The output signal can be set in the configuration. Upon delivery, all of the ana-
log outputs are set to the same signal (see the type plate).
Output signal 0 to 20 mA
4 to 20 mA
0 to 10 V
2 to 10 V
1 to 5 V
Signal range 0.0 to 21.5 mA 0.0 to 10.5 V
Load impedance R
L
≤ 600 Ω ≥ 2 kΩ
Turn down 4:1 4:1
