5 | Operation FISCHER Mess- und Regeltechnik GmbH
80/108 BA_EN_FT90
5.5.3 Switch output
Path: \Configuration\Switch output
Level: 2
\...\Switch output
1 2 3 4
SP1 assignment
SP1 on
SP1 off
SP1 delay on
A
U
Fig.117: Switch output
NOTICE!As the configuration for each switch output is the same, only the
parameters for the first switch output are shown here.
Menu name Description
SP1 assignment A This menu is used to assign switch
output 1 to a channel or to switch it off.
SP1 on The activation point is set with this
parameter.
SP1 off The deactivation point is defined with
this parameter.
SP1 delay on The activation delay is defined with this
parameter.
SP1 delay off The deactivation delay is defined with
this parameter.
SP1 function A The contact point is defined with this
menu.
Back E This is the menu exit point. It takes you
back to the configuration menu.
5.5.3.1 SP1 assignment
Path: \Configuration\Switch output\SP1 assignment
Level: 3
\...\...\SP1 assignment
1 2 3 4
Inactive
Channel 1
S
U
R
RChannel 2
Channel 3 R
Fig.118: SP1 assignment
This menu can be used to assign or deactivate the switch point of a channel.
