5.4 Quick access
Path: \Quick access
Level: 1
\Quick access
Language
Designation
Meas.range C1 unit
Meas.range C1 start
A
A
U
1 2 3 4
Fig.70: Quick access
This menu allows quick access to some of the most important parameters of the
measuring channels. The menu for devices with three measuring channels (C1,
C2, C3) is displayed. In versions with two measuring channels, the parameters
of the third channel (C3) are hidden.
Menu name Description
Language A This menu can be used to select a
defined language as the menu lan-
guage.
Designation A designation for the measuring point
is entered in this menu item.
Meas.range C1 unit A A defined unit for the 1st measuring
channel can be selected in this sub-
menu.
Meas.range C1 start The start of the measuring range of the
1st measuring channel is defined with
this parameter.
Meas.range C1 end The end of the measuring range of the
1st measuring channel is defined with
this parameter.
Damping C1 This parameter can be used to set
damping for the 1st measuring chan-
nel.
Meas.range C2 unit A A defined unit for the 2nd measuring
channel can be selected in this sub-
menu.
Meas.range C2 start The start of the measuring range of the
2nd measuring channel is defined with
this parameter.
Meas.range C2 end The end of the measuring range of the
2nd measuring channel is defined with
this parameter.
Damping C2 This parameter can be used to set
damping for the 2nd measuring chan-
nel.
Meas.range C3 unit A A defined unit for the 2nd measuring
channel can be selected in this sub-
menu.
Meas.range C3 start The start of the measuring range of the
3rd measuring channel is defined with
this parameter.
Meas.range C3 end The end of the measuring range of the
3rd measuring channel is defined with
this parameter.
