4.2.1 Measured value display
Depending on the unit model, there are different presentation variants for the
measured value display.
4.2.1.1 2-channel version T/rH
Assignment:
Channel 1: Temperature
Channel 2: Humidity
The display can be changed using the 'Meas.data display' menu. You
can display the channels individually or at the same time. The bar graph display
always shows both measuring channels.
Measurement point 1
°C
Pa21.4
C1
1 2 3 4
Measurement point 1
C1
C2 %rF
Pa21.4
Pa54.6
1 2 3 4
°C
U
Channel 1
Channel 1
Channel 2
Measurement point 1
%rF
Pa54.6
C2
1 2 3 4
Channel 2
Indicator Colour change
Switching outputs
Fig.31: Measuring data display (2 channels)
