FISCHER FT90 - Analog Output 1 Type; Analog Output 1 Assignment

5 | Operation FISCHER Mess- und Regeltechnik GmbH
78/108 BA_EN_FT90
5.5.2.1 Analog output 1 type
Path: \...\...\An.output 1 type
Level: 3
\...\...\An.output 1 type
1 2 3 4
Current 0...20 mA
Current 4...20 mA
Voltage 0...10 V
Voltage 2...10 V
S
R
U
R
R
Fig.114: Analog output 1 type
The signals can be set for output 1:
Current signals Voltage signals
0 … 20 mA 0 … 10 V
4 … 20 mA 2 … 10 V
1 … 5 V
5.5.2.2 Analog output 1 assignment
Path: \Configuration\Analog output\An.output 1 assignment
Level: 3
An.output 1 assignmnt
1 2 3 4
Channel 1
Channel 2
Back
S
E
U
R
Channel 3 R
Fig.115: An.output 1 assignment
The assignment of the analog outputs to the channels can be set freely. In the
case of a device with two channels, the third channel is hidden.
