7.9.2 Dimensional drawings
All dimensions in mm unless otherwise stated
120
94
81.5
39
92
Process connection
Electrical
connection
Mounting rail
26
49
26 29
Mounting rail
Blind plug
(a) Version with pressure connection
(b) Version without pressure connection
Process connection
Blind plug
FF90 T/rH Sensor
Removable disk
Fig.142: Dimensional drawing
