8 | Order code FISCHER Mess- und Regeltechnik GmbH
102/108 BA_EN_FT90
Humidity and temperature measuring range:
[3,4] Measuring range Sensor material
10 Humidity 0 to 100% rH
Temperature -40 to 100°C
Plastic (POM)
20 Humidity 0 to 100% rH
Temperature -40 to 100°C
Stainless steel
Process connection:
[5,6]
00 without
40 Aluminium CK screw connection for 6/4 mm hose
41 Aluminium CK screw connection for 8/6 mm hose
P6 Nickel-plated brass pneumatic plug-in connector for 6/4 mm hose
P8 Nickel-plated brass pneumatic plug-in connector for 8/6 mm hose
24 Stainless steel cutting ring connection for 6 mm pipe
25 Stainless steel cutting ring connection for 8 mm pipe
Output signal:
[7]
0 without
Switchable, factory pre-set:
C 0 … 10 V
A 0 … 20 mA
P 4 … 20 mA
Digital interface:
M RS485 Modbus RTU
Special functions:
[8]
0 None
Special aspects:
[9]
0 None
1 Sensor with increased overload and bursting pressure strength of
1 bar only for the following pressure ranges:
52 0 to 4 mbar D7 0 to 400 Pa
53 0 to 6 mbar D8 0 to 600 Pa
54 0 to 10 mbar N1 0 to 1 kPa
A6 -2.5 to +2.5 mbar L6 -250 to +250 Pa
A7 -4 to +4 mbar R1 -400 to +400 Pa
A8 -6 to +6 mbar R2 -600 to +600 Pa
A9 -10 to +10 mbar L8 -1 to +1 kPa
Approval and housing/lid colour:
[13,14] Approval Housing colour Lid colour
00 None Anthracite Green
R1 ATEX zones 2 and 22 Black
(conductive housing)
Black
