Configuration -> Channel -> Flow rate mode
Login
Level 0
Level 1
Quick Access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Channel 3
3-channel version
Measurement C1
Level 2
Mode C1
Flow rate
Level 3
Linear
Table
Volume flow
Linear function
Characteristic C1
Displ.range C1 unit
Displ.range C1 start
Displ.range C1 end
Menu expansion
Fig.40: 'Configuration/Channel/Flow rate/Characteristic' submenu
Configuration -> Channel -> Table mode
Login
Level 0
Level 1
Quick access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Channel 3
3-channel version
Measurement C1
Level 2
Mode C1
Linear
Level 3
Flow rate
Table
Volume flow
Linear function
Characteristic C1
Displ.range C1 unit
Table C1
menu expansion
Fig.41: Configuration/Channel/Table menu expansion
