5.1.3.3.2 Configuration -> Analog output
Login
Level 0
Level 1
Quick access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Login
Level 0
Level 1
Quick access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Channel 3
2-channel version 3-channel version
An.output 1 type
Output 1 assignment
An.output 2 type
Output 2 assignment
Limit I min.
Limit I max.
I error signal
Limit U min.
Limit U max.
U error signal
Level 2
An.output 1 type
Output 1 assignment
An.output 2 type
Output 2 assignment
Limit I min.
Limit I max.
I error signal
Limit U min.
Limit U max.
U error signal
Level 2
An.output 3 type
Output 3 assignment
Fig.44: 'Configuration/Channel/Analog output' submenu
5.1.3.3.3 Configuration -> Switch output
Login
Level 0
Level 1
Quick access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Login
Level 0
Level 1
Quick access
Configuration
Info
Service
Channel 1
Channel 2
Analog output
Switch output
Display
Channel 3
2-channel design 3-channel design
SP1 assignment
Level 2
SP1 on
SP1 off
SP1 delay on
SP1 delay off
SP1 function
SP2 assignment
SP2 on
SP2 off
SP2 delay on
SP2 delay off
SP2 function
SP3 assignment
SP3 on
SP3 off
SP3 delay on
SP3 delay off
SP3 function
SP4 assignment
SP4 on
SP4 off
SP4 delay on
SP4 delay off
SP4 function
SP1 assignment
Level 2
SP1 on
SP1 off
SP1 delay on
SP1 delay off
SP1 function
SP2 assignment
SP2 on
SP2 off
SP2 delay on
SP2 delay off
SP2 function
SP3 assignment
SP3 on
SP3 off
SP3 delay on
SP3 delay off
SP3 function
SP4 assignment
SP4 on
SP4 off
SP4 delay on
SP4 delay off
SP4 function
Fig.45: 'Configuration/Switch output' submenu
