Instruction
Display Shows
1
Press the +1 or –1 keys until memory address 8
is shown in the display
ADDR:8 PROG:20
End Program
2
Press the Enter key, then to change to page
2. Select Step & Repeat X.
Step & Repeat X
Columns(X):
Rows(Y):
3
Type 4 to specify four columns, then press
ENTER.
Step & Repeat X
Columns(X):4
Rows(Y):
4
Type 3 to specify three rows, then press ENTER.
Columns(X):4
Rows(Y):3
X Offset: (mm)
Y Offset: (mm)
5
In the above example, the X Offset between
parts is 30 mm.
Type 30 to specify an X Offset of 30 mm, then
press ENTER.
Columns(X):4
Rows(Y):3
X Offset:30 (mm)
Y Offset: (mm)
6
In the above example, the Y Offset between
parts is 25 mm.
Type 25 to specify 25 mm, then press ENTER.
Rows(Y):3
X Offset:30 (mm)
Y Offset:25 (mm)
Start Addr:
7
The display will prompt you for the Start Addr:
The start address is the memory address of the
first instruction which is part of this Step &
Repeat group. In our example, we want to repeat
all instructions starting with memory address
number 4.
Type 4 to specify memory address 4, then press
ENTER.
Start Addr:4
1.S Path
2.N Path
Select:
