Flintec DAD143 Series User Manual

DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 18 of 95
6.4 Menu 2 System Span
Remark: Activate a new calibration with 1x Power OFF & ON !
2.
SPAN setup (Menu 2.1 to 2.4) TAC protected see chapter 10.2.1
2.1
Set SPAN Calibration value (command CG)
-
Set display value equivalent to calibration weight or to mV/V value derived
from load cell(s) test data.
2.2
Calibrate system SPAN - gravimetric by weight / load
-
Display shows the actual input signal in mV/V.
-
Apply test weight equivalent to calibration value (2.1).
-
Press ENTER button to store new SPAN signal.
2.3
Calibrate system SPAN - electronic by mV/V input (command AG)
-
Use the UP/DOWN & MOVE RIGHT keys to setup the mV/V value at which
the device should read SPAN.
-
Press ENTER button to store new SPAN signal.
2.4
Display the input signal in mV/V
-
This function displays the actual input signal of the load cell(s).
2.5
Display the firmware version, e.g. 1.47 (command IV)
-
Read and display the firmware version.
2.6
Display the actual TAC value, e.g. 34 (command CE)
-
Read and display the TAC value of the actual calibration.
