DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 57 of 95
9.11 Analog Output AA, AH, AL, AM, AR (only in DAD 143.1)
The following commands must be saved in EEPROM by command AS.
9.11.1 AA Analog Output Base
[Index 0x2100 Sub 0x01]
Slave (DAD143.x) responds
Request: base is gross value
Setup: base is Peak value
You can choose one out of the following analog output base:
0 - analog output follows Gross value ( )
1 - analog output follows Net value (nE )
2 - analog output follows Peak value ( )
3 - analog output follows Average value ( )
4 - analog output follows Hold value (
H
)
5 - analog output follows Peak - Peak value ( )
6 - analog output follows Valley value ( )
7 - analog output follows Display value (
I
)
8 - analog output is switched OFF ( )
9 - analog output follows Mass flow value ( firmware type 2 only)
10 analog output follows Analog Reference value ( )
9.11.2 AH Set Analog High Level
[Index 0x2100 Sub 0x02]
Request / Set up high level for analog output. Permitted values are -999 999 ... +999 999d.
Slave (DAD143.x) responds
Request: setting 10 000 d
9.11.3 AL Set Analog Low Level
[Index 0x2100 Sub 0x03]
Request / Setup low level for analog output. Permitted values are -
Slave (DAD143.x) responds
9.11.4 AM Set Analog Output Mode
[Index 0x2100 Sub 0x15]
Request / Setup mode for analog output. Permitted values are 0 ... 5.
Slave (DAD143.x) responds
Request: setting 4 to 20mA
You can choose one out of the following analog output modes:
9.11.5 AR Set Analog Reference Value
[Index 0x2100 Sub 0x19]
Setup of a reference value for the analog output.
Permitted values are -999999 ... +999999, based on the cmd settings of AL and AH, see above.
