DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 49 of 95
Leading
character
signifies the GW
Net weight
excluding
decimal point
Gross weight
excluding decimal
point
First
bitmapped
binary value
Second
bitmapped
binary value
The bitmapped characters are:
First bitmapped
value description
Second bitmapped
value description
1 Not used
2 Output 0 active
4 Output 1 active
8 Output 2 active
1 No motion
2 Zero action performed
4 Tare active
8 Not used
The checksum is derived as follows:
a. Add the ASCII values (in hex) of all 17 characters in the string (result in hex is 351)
b. Take the last two numbers (in hex 51)
c. Invert the sign (result is FFFFFFFFAF)
d. Use only the last two charachters (AF)
e. Checksum is AF
9.6.6 OF Output Format for Data String GW
Note: This command is only relevant for the serial interface RS 232.
GL output response.
Slave (DAD143.x) responds
Request: TAC counter CE17
Calibration sequence active
Decimal Point in GW response
When the range information is selected, the data strings will change from G+000000 to Gn+000000,
where 1 n 3.
9.6.7 GA Get Triggered Average Value
[Index 0x2000 or 0x2001 / Sub 0x06] and [Index 0x2900 Sub 0x06]
This command reads the measurement result of a measurement cycle. The measurement value has been
averaged according the defined measuring time. The trigger commands can be found in chapter 10.13.
Slave (DAD143.x) responds
Note: For preventing errors during the read out of the data the register GA has stored the value 99999 at the
beginning of the measurement cycle. The measurement result can only be read after the defined measuring
time MT has been elapsed and before a new measurement cycle has been started.
