DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 42 of 95
9.2.20 AG Absolute gain calibration (eCal)
[Index 0x2300 Sub 0x01]
The command AG is used as absolute gain (or measuring range) for all weight calculations and will setup in
mV/V. Permitted values are ± 33 000 (= ± 3.3000 mV/V).
Slave (DAD143.x) responds
Request: gain 10 000d @ 0.1868 mV/V
Request: TAC counter CE17
Calibration sequence active
New: gain 5 000d @ 1.12 mV/V
Factory default: 10 000d @ 2.0000mV/V input signal.
9.2.21 CS Save the Calibration Data
[Index 0x2004 Sub 0x02]
This command results in the calibration data being saved to the EEPROM and causes the TAC to be
incremented by +1.
Slave (DAD143.x) responds
Request: TAC counter CE17
Calibration sequence active
The CS command saves all of the calibration group values, as set by AG, AZ, CZ, CG, CM, DS, DP and ZT. The
command returns ERR and has no updating action unless it was preceded by the CE_XXXXX.
9.2.22 SU Save User Setup in EEPROM
This command saves all the setup data including calibration non-volatile in EEPROM. In delivery status the
user setup contains the factory default settings (as FD command).
Slave (DAD143.x) responds
Request: TAC counter CE17
User setup stored in EEPROM
9.2.23 RU Restore User Setup to DAD143.x
This command restores the user setup including the calibration from the EEPROM, the TAC counter is
increased by +1.To activate, the SR command (warm start) must be performed or just re-start the DAD 143.
Slave (DAD143.x) responds
Request: TAC counter CE17
Activate restored user setup
9.2.24 FT Firmware Type
[Index 0x2300 Sub 0x15]
The DAD143.x with firmware version 143.x81.v.1.01 or higher can be used to run different applications. The
respective firmware type can be freely selected with the FT command.
The different firmware types of FT are:
FT = 0 is the basic version with checkweigher functions, content of this manual.
The device ID for this firmware type is 1430.
FT = 1
fine feed. The device ID for this firmware type is 1434.
FT = 3
The device ID for this firmware type is 1436.
Factory default: FT=0.
