DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 58 of 95
9.12 Save Calibration and Setup CS, WP, SS, AS, GI, PI
The calibration and setup parameters can be divided in 4 groups:
• Calibration: CM, DS, DP, CZ, CG, ZT, IZ and FD, etc. saved by command CS
• Setup: FL, FM, NR, NT, BR, AD, DX and others, saved by command WP
• Setpoints: S1, S2, S3, H1, H2, H3, A1, A2, A3 - saved by command SS
• Analog outputs: AA, AH, AL, AM - if available - saved by command AS
Note: Calibration data can only be saved if the TAC code is known and preceding the CS command. See the
commands CE and CS in chapter 10.2.
The setup data and the setpoint data will be stored non-volatile in the EEPROM using the WP respective SS
and AS command.
9.12.1 CS Save the Calibration Data
[Index 0x2004 Sub 0x02]
This command results in the calibration data being saved to the EEPROM and causes the TAC to be
incremented by 1.
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
CE
E+00017 (example)
Request: TAC counter CE17
CE 17
OK
Calibration sequence active
CS
OK
Calibration values saved
The CS command saves all of the calibration group values, as set by AG, AZ, CZ, CG, CM, DS, DP, ZT etc. The
command returns ERR and has no updating action unless it is proceded by the CE_XXXXX.
9.12.2 WP Save the Setup Parameters
[Index 0x2004 Sub 0x03]
-
the communication (AD, BR, DX) will be saved in the EEPROM.
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
WP
OK
Setup data saved
WP
ERR
Error
9.12.3 SS Save Setpoint Parameters
[Index 0x2004 Sub 0x05]
With this command the setpoints (S0, S1, S2), the setpoint hysteresis (H0, H1, H2) and the setpoint allocation
(A0, A1, A2) will be saved in the EEPROM.
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SS
OK
Setpoint parameters saved
SS
ERR
Error
9.12.4 AS Save Analog Output Parameters (only DAD 143.1)
[Index 0x2004 Sub 0x01]
With this command the action (AA), the analog low (AL), the analog high (AH) and the output mode (AM) will
be saved in the EEPROM.
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
AS
OK
Analog output parameters saved
AS
ERR
Error
9.12.5 GI Get an Image File from the EEPROM
Retrieves a HEX-INTEL formatted EEPROM image file from the EEPROM of the source DAD143.x. The image
file contains all stored information except the calibration data. This image file can be downloaded to any
DAD143.x with the same firmware type and revision no. as the source DAD143.x.
