Flintec DAD143 Series User Manual

DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 67 of 95
14 Cyclic Data Transfer - ProfiNet
Measuring data and status information from the DAD is sent cyclic to the PLC as a complete data package.
Simple commands (Tare, zero, etc) are also sent as cyclic data from the PLC to the DAD. An additional
mechanism in the cyclic data transfer allow the PLC to send commands to the DAD and the reply to be sent
back to the PLC. Please note that these commands can also be send as acyclic data.
14.1 Data sent from the DAD 143.x to the PLC
14.1.1 Data package sent from the DAD 143.x
The DAD 143.x sends a fixed size 21 byte array to the PLC. These bytes shall be interpreted as follows:
Variable name
Data type
Index of first
byte
CmdStatus
Unsigned32
0
CmdRdData
Integer32
4
Data1
Float32
8
Data2
Float32
12
Qualifier
Unsigned16
16
IoStatus
Unsigned8
18
DataType1
Unsigned8
19
DataType2
Unsigned8
20
14.1.2 CmdStatus
When a command is sent to the DAD through the cyclic data exchange system this variable will hold a status
information telling how the execution of the command went.
Bit 31
Bit 30
Bit 29
Bit 28
Bit 27
Bit 26
Bit 25
Bit 24
Bit 23
Bit 22
Bit 21
Bit 20
Bit 19
Bit 18
Bit 17
Bit 16
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
Not used
0
ACK
Not used
0
Not used
0
Not used
0
Status bit
3
Status bit
2
Status bit
1
Status bit
0
Bit 7 is an acknowledge bit and it will toggle everytime the status information is updated.
The lower four bits (0 to 3) contain the status code:
Status
code
Bit
3
Bit
2
Bit
1
Bit
0
Meaning
0
0
0
0
0
No error - OK
1
0
0
0
1
Index does not exist
2
0
0
1
0
Subindex does not exist
3
0
0
1
1
The given parameter is out of range
4
0
1
0
0
Calibration lock not open
5
0
1
0
1
The command is not allowed
6
0
1
1
0
Attempt to read a write-only parameter
7
0
1
1
1
Attempt to write a read-only parameter
8
1
0
0
0
-
9
1
0
0
1
Command failed
10
1
0
1
0
Zeroing disabled
11
1
0
1
1
Out of zero range
12
1
1
0
0
Input range exceeded
13
1
1
0
1
Load cell connection error
14
1
1
1
0
Reading not stable
15
1
1
1
1
Out of tare range
