2 Specifications
DAD 143.x Specifications
Accuracy class
III
Test certificate according OIML R76
EU Type approved for 10000 intervals
AD converter
Delta-Sigma, ± 24 bit
Analog input range
±15 mV bipolar (± 3 mV/V @ 5 VDC excitation)
Minimum input sensitivity
0.2 μV/e (legal for trade); 0.05 μV/d (non legal for trade)
Linearity
< 0.001 % FS
Temperature effect on zero
< ±4 ppm/°K (typical < ±2 ppm/°K)
Temperature effect on span
< ±8 ppm/°K (typical < ±4 ppm/°K)
Excitation
5 V DC, load cell(s) resistance 50 - 2000 ohms; 6-wire technics
Conversion rate
Max. 600 values/second, selectable in 8 steps
Resolution external
± 600 000 counts @ ± 3 mV/V input signal
CALIBRATION & WEIGHING FUNCTIONS
Calibration
Electronical calibration in mV/V (eCal) or with test weight(s)
Digital low pass filter
FIR Filter 2.5 to 19.7 Hz or IIR Filter 0.25 to 18 Hz - adjustable in 8 steps
Weighing functions
Zero, gros, tare, net, filter, etc.
Application modes
Nonautomatic weighing instrument (NAWI) or triggered measurement
Communication & Setup
Communication ports
RS232 and Ethernet
Setup & Calibration
via front panel butt
Display
green,
spectral filter 565 nm for improved contrast
Keyboard
4 pcs, Ø 3mm robust, for setup / calibration, zero, tare
Power supply
10 ... 30 VDC, < 4.0 W @ 24 VDC
Environmental Conditions
Operating temperature
-15 °C to +55 °C at maximal 85% rh, non-condensing
Storage temperature
-30 °C to +70 °C
Enclosure & protection
Plastic housing, for DIN rail mount (TS35) , protection IP40
Dimensions and weight
120 x 102 x 23 mm (L x H x W), weight approx. 170 g
Vibration resistance
2.5g @ operation, 5g @ storage
Service Port
RS 232, 9600 ... 460800 Baud half/full duplex
Protocol & Address range
ASCII; address range 255
Ethernet Ports (2 pcs.)
RJ45, 10/100 Mbit/s, integrated 2 port switch, isolated
Duplex modes
Half Duplex, Full Duplex, Auto-Negotiation
MDI modes
MDI, MDI-X, Auto-MDIX
Data transport layer
Ethernet II, IEEE 802.3
Analog current output (DAD143.1 only)
0 20mA or 4 20mA, 500ohm, isolated or
Analog voltage output (DAD143.1 only)
0 10V, 0 5V, ±5V, ±10V, 10kohm, isolated
Digital logic inputs
2 inputs (10 30V, 1 3mA), commond ground, isolated
Digital logic outputs
3 outputs (semiconductor relais) 30 V DC/AC, 0.5 A,
common ground, isolated
