DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 51 of 95
9.7.1 SG Send Gross Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SG
G+001.100
Gross value: 1,100 d
9.7.2 SN Send Net Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SN
N+001.000
Net value: 1,000 d
9.7.3
Issuing the SW command, which has no parameters, will return continously the net weight, the gross weight,
the status and the checksum values, all combined into one single string in the format
W+000100+001100010F.
For more detailed information of the data string see command GW (chapter 10.6.5).
9.7.4 SA Send Triggered Average Value automatically
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SA
OK
Auto-Transmit: triggered average value
This command will start to auto-transmit the measurement value of the current trigger cycle. The trigger
setup commands are described in the chapters 10.13.4 to 10.13.7.
9.7.5 SH Send Hold Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SH
H+001.100
Hold value: 1,100 d
9.7.6 SM Send Peak Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SM
M+001.100
Peak value: 1,100 d
9.7.7 SO Send Peak To Peak Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SO
O+001.100
Peak to Peak value: 1,100 d
9.7.8 SV Send Valley Value continuously
Master (PC / PLC) sends
Slave (DAD143.x) responds
Meaning
SV
V+000.100
Valley value: 100 d
