DAD 143.x User Manual Profinet Rev.1.1.1 March 2023 Page 32 of 95
Logic input: for each Input Status 0 or 1
Logic output: for each Output Status 0 or 1
Device information: Identify Device Status
Device information: Identify Firmware Version
Last Error occurred in DAD143.x, showing a code between 0 and 15
Calibration: Define Multi-interval (0) or Multi-range (1)
Trigger function: Measuring Time for Averaging
Show one (of the four) MAC addresses assigned to the DAD143.x
Network address (IP address) <aaa.bbb.ccc.ddd>
Motion detection: No-motion Range
Motion detection: No-motion Time Period
Output Format of Data String GL and GW
Output Mask to control hy host
Protocol select: 1 ProfiNet, 2 Ethernet/IP, 3 EtherCAT, 4 Modbus TCP
Reset Peak (Maximum) Value
Device information: Read serial number
Scale function: Reset Tare and Switch to Gross Indication
Scale function: Reset Zero Point
Auto-transmit: Send Triggered Average Value automatically
Trigger function: Start Delay
Auto-transmit: Send Gross Value continuously
Auto-transmit: Send Hold Value
Auto-transmit: Send Peak (Maximum) Value
Auto-transmit: Send Net Value continuously
Setup of Setpoints S0, S1 and S2
Auto-transmit: Send Peak to Peak Value
Reset Firmware (Warm Start)
Scale function: Set Tare and Switch to Net Indication
Auto-transmit: Send Valley Value
Scale function: System Zero Point
Trigger function: Trigger on Rising Edge (1) or Falling Edge (0)
Trigger Hold (save the actual weight/reading)
Trigger function: Averaging Time for Automatic Taring
Trigger function: Trigger Level
Non Volatile Tare value ON/OFF @ power OFF
Trigger function: Software Trigger
Trigger function: Window for Automatic Taring
