Fluke 5522A - Page 404

5522A
Operators Manual
11-34
Table 11-1. PQ Option Verification Table (cont.)
Verification Tests for
AC Current
Harmonic Fundamental Phase
Amplitude
(A)
Specification
(A)
Specification
(deg)
Range 20.5 A rms 5.80000 0.0216
Wave IECD 1 100.00% 5.04200 0.0150
RMS Output 5.8 A 3 46.90% 180 2.36600 0.0150 0.6
Frequency 50Hz 5 26.20% 0 1.32200 0.0150 0.6
7 13.80% 180 0.69600 0.0150 0.6
9 6.90% 0 0.34800 0.0150 0.6
11 4.80% 180 0.24360 0.0150 0.6
13 4.10% 0 0.20612 0.0150 0.6
15 3.50% 180 0.17864 0.0150 0.6
17 3.10% 0 0.15763 0.0150 0.6
19 2.80% 180 0.14103 0.0150 1.0
21 2.50% 0 0.12760 0.0150 1.0
23 2.30% 180 0.11651 0.0150 1.0
25 2.10% 0 0.10719 0.0150 1.0
27 2.00% 180 0.09924 0.0150 1.0
29 1.80% 0 0.09250 0.0150 1.0
31 1.70% 180 0.08644 0.0150 1.0
33 1.60% 0 0.08120 0.0150 1.0
35 1.50% 180 0.07656 0.0150 1.0
37 1.40% 0 0.07242 0.0150 1.0
39 1.40% 180 0.06871 0.0150 1.0
Range 20.5 A rms 9.50000 0.0290
Wave NRC7030 1 100.00% 8.53100 0.0185
RMS Output 9.5 A 2 10.00% -115.5 0.85313 0.0185 0.6
Frequency 60Hz 3 10.00% 1.1 0.85313 0.0185 0.6
4 10.00% -179.6 0.85313 0.0185 0.6
5 10.00% 13.3 0.85313 0.0185 0.6
6 10.00% 9.3 0.85313 0.0185 0.6
7 10.00% 73.5 0.85313 0.0185 0.6
8 10.00% 152.1 0.85313 0.0185 0.6
9 10.00% -19.9 0.85313 0.0185 0.6
10 10.00% -167.8 0.85313 0.0185 0.6
11 10.00% 85.9 0.85313 0.0185 0.6
12 10.00% -37.3 0.85313 0.0185 0.6
13 10.00% 16.1 0.85313 0.0185 0.6
14 10.00% -28.1 0.85313 0.0185 0.6
15 10.00% 94 0.85313 0.0185 0.6
16 10.00% -173.4 0.85313 0.0185 1.0
17 10.00% 129.5 0.85313 0.0185 1.0
18 10.00% -113.9 0.85313 0.0185 1.0
19 10.00% 37.6 0.85313 0.0185 1.0
20 10.00% -52.3 0.85313 0.0185 1.0
21 10.00% 1.5 0.85313 0.0185 1.0
22 10.00% 14.3 0.85313 0.0185 1.0
23 10.00% 150.2 0.85313 0.0185 1.0
24 10.00% 7.1 0.85313 0.0185 1.0
25 10.00% 161.3 0.85313 0.0185 1.0
