5522A
Operators Manual
11-28
Performance Tests
To verify the PQ option meets its specifications, refer to the performance tests in this
section. The tables are for use by qualified metrology personnel only.
These tables refer to waveforms that are described elsewhere in this manual, as well as
other special waveforms that need to be created in the Composite Harmonics mode. Note
that all tests should be performed with the 5522A EARTH key enabled.
Verification Table
Table 11-1. PQ Option Verification Table
Verification Tests for AC
Voltage
Harmonic Fundamental Phase
Amplitude
(V)
Specification
(V)
Specification
(deg)
Range 329.99 mV rms 0.12000 2.500E-04
Wave I 1 100.00% 0.03000 9.00E-5
RMS Output 0.12 V 3 100.00% 0 0.03000 9.00E-5 0.5
Frequency 50.0 Hz 6 100.00% 0 0.03000 9.00E-5 0.5
9 100.00% 0 0.03000 9.00E-5 0.5
12 100.00% 0 0.03000 9.00E-5 0.5
15 100.00% 0 0.03000 9.00E-5 0.5
16 100.00% 0 0.03000 9.00E-5 0.5
23 100.00% 0 0.03000 9.00E-5 0.8
28 100.00% 0 0.03000 9.00E-5 0.8
33 100.00% 0 0.03000 9.00E-5 0.8
38 100.00% 0 0.03000 9.00E-5 0.8
43 100.00% 0 0.03000 9.00E-5 2.0
48 100.00% 0 0.03000 9.00E-5 2.0
53 100.00% 0 0.03000 9.00E-5 2.0
58 100.00% 0 0.03000 9.00E-5 2.0
63 100.00% 0 0.03000 9.00E-5 2.0
Range 3.2999 V rms 0.45000 0.001000
Wave I 1 100.00% 0.11250 0.000513
RMS Output 0.45 V 3 100.00% 0 0.11250 0.000513 0.5
Frequency 60 Hz 6 100.00% 0 0.11250 0.000513 0.5
9 100.00% 0 0.11250 0.000513 0.5
12 100.00% 0 0.11250 0.000513 0.5
15 100.00% 0 0.11250 0.000513 0.5
16 100.00% 0 0.11250 0.000513 0.8
23 100.00% 0 0.11250 0.000513 0.8
28 100.00% 0 0.11250 0.000513 0.8
33 100.00% 0 0.11250 0.000513 0.8
38 100.00% 0 0.11250 0.000513 2.0
43 100.00% 0 0.11250 0.000513 2.0
48 100.00% 0 0.11250 0.000513 2.0
53 100.00% 0 0.11250 0.000513 2.0
58 100.00% 0 0.11250 0.000513 2.0
63 100.00% 0 0.11250 0.000513 2.0
Range 32.999 V rms 12.0000 0.0250
Wave I 1 100.00% 3.0000 0.0070
RMS Output 12 V 3 100.00% 0 3.0000 0.0070 0.3
Frequency 60 Hz 6 100.00% 0 3.0000 0.0070 0.3
9 100.00% 0 3.0000 0.0070 0.3
