PQ Option
Verification Table11
11-29
Table 11-1. PQ Option Verification Table (cont.)
Verification Tests for AC
Voltage
Harmonic Fundamental Phase
Amplitude
(V)
Specification
(V)
Specification
(deg)
12 100.00% 0 3.0000 0.0070 0.3
15 100.00% 0 3.0000 0.0070 0.3
16 100.00% 0 3.0000 0.0070 0.5
23 100.00% 0 3.0000 0.0070 0.5
28 100.00% 0 3.0000 0.0070 0.5
33 100.00% 0 3.0000 0.0070 0.5
38 100.00% 0 3.0000 0.0070 2.0
43 100.00% 0 3.0000 0.0070 2.0
48 100.00% 0 3.0000 0.0070 2.0
53 100.00% 0 3.0000 0.0070 2.0
58 100.00% 0 3.0000 0.0070 2.0
63 100.00% 0 3.0000 0.0070 2.0
Range 329.99 V rms 210.0000 0.4300
Wave II 1 100.00% 91.6730 0.3917
RMS Output 210 V 2 100.00% 0 91.6730 0.3917 0.75
Frequency 60 Hz 3 100.00% 0 91.6730 0.3917 0.75
5 100.00% 0 91.6730 0.3917 0.75
7 100.00% 0 91.6730 0.3917 0.75
8 30.00% 0 27.5020 0.3917 1.0
12 30.00% 0 27.5020 0.3917 3.0
13 10.00% 0 9.1670 0.3917 3.0
16 10.00% 0 9.1670 0.3917 3.0
18 10.00% 0 9.1670 0.3917 3.0
21 10.00% 0 9.1670 0.4984 5.0
23 10.00% 0 9.1670 0.4984 5.0
25 10.00% 0 9.1670 0.4984 5.0
26 5.00% 0 4.5840 0.4984 5.0
30 5.00% 0 4.5840 0.4984 5.0
33 5.00% 0 4.5840 0.4984 5.0
Range 1020 V rms 600.0000 1.300
Wave III 1 100.00% 241.796 1.310
RMS Output 600 V 2 100.00% 0 241.796 1.310 0.75
Frequency 50 Hz 3 100.00% 0 241.796 1.310 0.75
5 100.00% 0 241.796 1.310 0.75
7 100.00% 0 241.796 1.310 0.75
8 100.00% 0 241.796 1.310 1.2
12 30.00% 0 72.539 1.310 1.2
13 10.00% 0 24.180 1.310 1.2
16 10.00% 0 24.180 1.310 3.0
18 10.00% 0 24.180 1.310 3.0
21 10.00% 0 24.180 1.310 3.0
23 10.00% 0 24.180 1.310 3.0
25 10.00% 0 24.180 1.610 5.0
26 5.00% 0 12.090 1.610 5.0
30 5.00% 0 14.1880 1.610 5.0
33 5.00% 0 14.1880 1.610 5.0
