Fluke 5522A - Page 400

5522A
Operators Manual
11-30
Table 11-1. PQ Option Verification Table (cont.)
Verification Tests for AC
Voltage
Harmonic Fundamental Phase
Amplitude
(V)
Specification
(V)
Specification
(deg)
Range 329.99 V rms 150.0000 0.3100
Wave IV 1 100.00% 54.627 0.1299
RMS Output 150 V 2 100.00% 0 54.627 0.1299 0.75
Frequency 50 Hz 3 100.00% 0 54.627 0.1299 0.75
4 100.00% 0 54.627 0.1299 0.75
5 100.00% 0 54.627 0.1299 0.75
6 100.00% 0 54.627 0.1299 0.75
7 100.00% 0 54.627 0.1299 0.75
8 30.00% 0 16.388 0.1624 0.75
9 30.00% 0 16.388 0.1624 1.0
10 30.00% 0 16.388 0.1624 1.0
11 30.00% 0 16.388 0.1624 1.0
12 30.00% 0 16.388 0.1624 1.0
13 30.00% 0 16.388 0.1624 1.0
Range 1020 V rms 450.0000 1.0000
Wave IV 1 100.00% 163.880 0.5122
RMS Output 450 V 2 100.00% 0 163.880 0.5122 0.75
Frequency 50 Hz 3 100.00% 0 163.880 0.5122 0.75
4 100.00% 0 163.880 0.5122 0.75
5 100.00% 0 163.880 0.5122 0.75
6 100.00% 0 163.880 0.5122 0.75
7 100.00% 0 163.880 0.5122 0.75
8 30.00% 0 49.164 0.5122 0.75
9 30.00% 0 49.164 0.5122 1.2
10 30.00% 0 49.164 0.5122 1.2
11 30.00% 0 49.164 0.5122 1.2
12 30.00% 0 49.164 0.5122 1.2
13 30.00% 0 49.164 0.5122 1.2
Range 32.999 V rms 12.00000 0.02500
Wave SQUARE 1 100.00% 10.87300 0.01487
RMS Output 12 V 3 33.30% 0 3.62100 0.01487 0.3
Frequency 60 Hz 5 20.00% 0 2.17500 0.01487 0.3
7 14.30% 0 1.55500 0.01487 0.3
9 11.10% 0 1.20700 0.01487 0.3
11 9.10% 0 0.98948 0.01487 0.3
13 7.70% 0 0.83725 0.01487 0.3
15 6.70% 0 0.72852 0.01487 0.3
17 5.90% 0 0.64153 0.01487 0.5
19 5.30% 0 0.57629 0.01487 0.5
21 4.80% 0 0.52193 0.01487 0.5
23 4.30% 0 0.46756 0.01487 0.5
25 4.00% 0 0.43494 0.01487 0.5
27 3.70% 0 0.40232 0.01487 0.5
29 3.40% 0 0.36970 0.01487 0.5
31 3.20% 0 0.34795 0.01487 0.5
