Table 11-1. PQ Option Verification Table (cont.)
Verification Tests for AC
Voltage
Harmonic Fundamental Phase
Amplitude
(V)
Specification
(V)
Specification
(deg)
Range 329.99 V rms 230.0000 0.4700
Wave NRC 7030 1 100.00% 206.5460 0.8512
RMS Output 230 V 2 10.00% -115.5 20.6550 0.8512 0.75
Frequency 50 Hz 3 10.00% 1.1 20.6550 0.8512 0.75
4 10.00% -179.6 20.6550 0.8512 0.75
5 10.00% 13.3 20.6550 0.8512 0.75
6 10.00% 9.3 20.6550 0.8512 0.75
7 10.00% 73.5 20.6550 0.8512 0.75
8 10.00% 152.1 20.6550 0.8512 0.75
9 10.00% -19.9 20.6550 0.8512 1.0
10 10.00% -167.8 20.6550 0.8512 1.0
11 10.00% 85.9 20.6550 0.8512 1.0
12 10.00% -37.3 20.6550 0.8512 1.0
13 10.00% 16.1 20.6550 0.8512 3.0
14 10.00% -28.1 20.6550 0.8512 3.0
15 10.00% 94 20.6550 0.8512 3.0
16 10.00% -173.4 20.6550 0.8512 3.0
17 10.00% 129.5 20.6550 0.8512 3.0
18 10.00% -113.9 20.6550 0.8512 3.0
19 10.00% 37.6 20.6550 0.8512 3.0
20 10.00% -52.3 20.6550 0.8512 3.0
21 10.00% 1.5 20.6550 0.8512 3.0
22 10.00% 14.3 20.6550 0.8512 3.0
23 10.00% 150.2 20.6550 0.8512 3.0
24 10.00% 7.1 20.6550 0.8512 3.0
25 10.00% 161.3 20.6550 1.0700 5.0
Verification Tests for AC Voltage (AUX)
Range 5 V rms 1.90000 0.00580
Wave V 1 100.00% 0.58524 0.00417
RMS Output 1.9 V 3 100.00% 0 0.58524 0.00417 0.75
Frequency 60 Hz 6 100.00% 0 0.58524 0.00417 0.75
9 100.00% 0 0.58524 0.00417 0.75
12 100.00% 0 0.58524 0.00417 0.75
16 100.00% 0 0.58524 0.00417 0.75
17 100.00% 0 0.58524 0.00417 2.0
23 100.00% 0 0.58524 0.00417 2.0
28 100.00% 0 0.58524 0.00417 2.0
33 100.00% 0 0.58524 0.00417 2.0
38 30.00% 0 0.17577 0.00476 3.0
43 30.00% 0 0.17577 0.00476 3.0
48 30.00% 0 0.17577 0.00476 3.0
53 30.00% 0 0.17577 0.00476 3.0
58 30.00% 0 0.17577 0.00476 3.0
63 30.00% 0 0.17577 0.00476 3.0
