Fluke 5522A - Page 402

5522A
Operators Manual
11-32
Table 11-1. PQ Option Verification Table (cont.)
Verification Tests for
AC Current
Harmonic Fundamental Phase
Amplitude
(A)
Specification
(A)
Specification
(deg)
Verification Tests for AC Current, LCOMP OFF
Range 329.9 mA rms 0.11000 1.22E-03
Wave VI 1 100.00% 0.03821 1.38E-04
RMS Output 0.11 A 3 100.00% 0 0.03821 1.38E-04 0.75
Frequency 50 Hz 6 100.00% 0 0.03821 1.38E-04 0.75
9 100.00% 0 0.03821 1.38E-04 0.75
12 100.00% 0 0.03821 1.38E-04 0.75
15 100.00% 0 0.03821 1.38E-04 0.75
18 100.00% 0 0.03821 1.38E-04 1.5
23 50.00% 0 0.01910 1.38E-04 1.5
28 50.00% 0 0.01910 1.38E-04 1.5
33 50.00% 0 0.01910 1.38E-04 1.5
38 30.00% 0 0.01146 1.38E-04 1.5
43 30.00% 0 0.01146 1.68E-04 3.0
48 30.00% 0 0.01146 1.68E-04 3.0
53 30.00% 0 0.01146 1.68E-04 3.0
58 30.00% 0 0.01146 1.68E-04 3.0
63 30.00% 0 0.01146 1.68E-04 3.0
Range 2.999 A rms 1.10000 0.00320
Wave VII 1 100.00% 0.40547 0.00141
RMS Output 1.1 A 3 100.00% 0 0.40547 0.00141 0.6
Frequency 50 Hz 6 100.00% 0 0.40547 0.00141 0.6
9 100.00% 0 0.40547 0.00141 0.6
12 100.00% 0 0.40547 0.00141 0.6
15 100.00% 0 0.40547 0.00141 0.6
18 20.00 % 0 0.40547 0.00141 0.6
23 20.00 % 0 0.08109 0.00141 1.0
28 20.00 % 0 0.08109 0.00141 1.0
33 20.00 % 0 0.08109 0.00141 1.0
38 20.00 % 0 0.08109 0.00141 1.0
43 20.00 % 0 0.08109 0.00211 2.0
48 20.00 % 0 0.08109 0.00211 2.0
53 20.00 % 0 0.08109 0.00211 2.0
58 20.00 % 0 0.08109 0.00211 2.0
63 20.00 % 0 0.08109 0.00211 2.0
Range 20.5 A rms 4.50000 0.0190
Wave VII 1 100.00% 1.6590 0.0117
Rms Output 4.5 A 3 100.00% 0 1.6590 0.0117 0.6
Frequency 50 Hz 6 100.00% 0 1.6590 0.0117 0.6
9 100.00% 0 1.6590 0.0117 0.6
12 100.00% 0 1.6590 0.0117 0.6
15 100.00% 0 1.6590 0.0117 0.6
18 100.00% 0 1.6590 0.0117 0.6
23 20.00% 0 0.3317 0.0117 1.0
28 20.00% 0 0.3317 0.0117 1.0
33 20.00% 0 0.3317 0.0117 1.0
38 20.00% 0 0.3317 0.0117 1.0
43 20.00% 0 0.3317 0.0133 3.0
48 20.00% 0 0.3317 0.0133 3.0
