Fluke 810 - View Other Data Files; Time Waveform

810
Users Manual
5-34
To make a PDF of the diagnosis data:
1. Click . A dialog to save the PDF file
opens.
2. Save the PDF file. A dialog to open the file
shows on the display.
3. Select the file and click Open.
View Other Data Files
With the Viewer software, you can view the diagnosis
details from other data files that uses the .mdf file format.
To view backup data:
1. Click
Other Data Files. The Open dialog
box shows on the display.
2. Browse to the .mdf database file that has the
diagnosis data.
3. Find and open the .mdf database file. You can
view the backup diagnosis data. See “View
Diagnosis” for more instructions.
4. Click Restore Main Database.
Time Waveform
A time waveform is available for each test location. The
time waveform data is useful for pattern recognition of
different problems.
To open the time waveform window:
1. Click on the location of interest.
2. Click Time waveform on the right side of the
pane.
