Transmission without Closed Coupling
The Tester cannot analyze drive trains with beveled gears
where the shaft changes direction at a 90 ° angle
between components. Table 4-4 is a list of the options for
a transmission without a closed coupling.
Table 4-4. Transmission without Closed Coupling Options
Selection Option Description
Yes
Coupling between motor
and next component
No
Is there a coupling between motor (driver) and the next component in
the drivetrain? Select Yes or No accordingly.
Pump
Fan
Compressor
Blower
Spindle
Gearbox
[1]
Belt drive
[1] [2]
Next component
Chain drive
[1] [2]
Scroll and select the next component in the drivetrain from the list.
Notes
[1]
If you select Gearbox, Belt drive, or Chain drive, the options for the details of the transmission drive appear. See “Transmission
Component” for related options.
[2]
These selections are unavailable if there is a flexible coupling between the motor and the next component.
