Viewer Software
Introduction
5
5-3
Introduction
The 810 Vibration Tester includes Viewer software that
lets you do tasks from a computer. With the basic
features of the software you can:
• import/export a Machine Setup from the Tester
• set up a new machine
• make a copy of a Machine Setup
• change a Machine Setup
• look at cited peaks graphs, vibration spectra, and
time waveforms
• zoom-in and zoom-out of data views
• make a backup of the diagnosis data from a
measured machine
• import and look at the thermographic image of a
machine
Additionally, you can configure the Machine Setups with
the software and export them to the Tester. This Machine
Setup procedure is much the same as the Machine Setup
wizard in the Tester. For external analysis of the fault
data, you can export the Machine Setup, diagnosis data,
and fault data to a PDF to send to a vibration test
consultant.
System Requirements
The minimum PC system requirements to use the Viewer
software are:
• Microsoft Windows 2000 / Windows XP / Windows
Vista / Windows 7 Operating system
• Minimum 1 GB RAM
• One USB port
• CD-ROM disk drive
PC Connections
To connect the computer to the Tester:
1. Power on the computer and the Tester.
2. Connect the USB cable to the USB ports of the
computer and the Tester as shown in Figure 5-1.
See the marking on the ends of the cable for
identifying the Type-A and Mini-B ends.
3. Install the supporting software and Viewer
software (if not installed already). See “Install the
Viewer Software”.
