Fluke 810 - Driven Component; Pump

Operation
Machine Setup
4
4-11
Driven Component
Depending on the component selection, the options for
the details of the driven component appear.
Pump
Table 4-5 is a list of the pump options.
Table 4-5. Pump Options for Driven Components
Selection Option Action Option Action Description
Roller --- --- ---
Bearing
type
Journal --- --- ---
Select the bearing type in the
pump.
Two bearings
Impeller is supported
by
Overhung
Scroll and identify the
impeller support.
Centrifugal
Number of vanes
(optional)
Input value between 2
and 20 with keyboard.
Propeller
Number of vanes
(optional)
Input value between 2
and 20 with keyboard.
Sliding
vanes
Number of vanes
(optional)
Input value between 2
and 20 with keyboard.
This is optional information.
Push Keyboard to access
the numeric keyboard. Enter
the number for the option.
Screw/lobe
Number of
teeth/lobes (optional)
Select 2 through 12
Pump
type
Piston
Scroll and
select the
pump type
Number of pistons
(optional)
Select 2 through 13
This is optional information.
Scroll and select the number.
