810
Users Manual
4-14
Blower
Table 4-8 is a list of the blower options.
Table 4-8. Blower Options for Driven Components
Option Selection Description
Roller
Driven component bearing type
Journal
Select the bearing type in the blower.
Number of blower lobes
Select 2 through 12
(optional)
Scroll and select the number of blower lobes.
Spindle
Only single or simple shafts can be analyzed with the Tester.
Transmission Component
If you select the component as Gearbox, Belt drive, or
Chain drive, the Setup Wizard shows the options for the
transmission component.
Gearbox
To diagnose gearbox faults properly, it is important to
characterize the gear ratios used. The Tester accepts any
of three possible methods: shaft speeds, gear tooth
counts, or gear ratios. The Tester cannot analyze drive
trains with beveled gears where the shaft changes
direction at a 90 ° angle between components.
If selecting the shaft speed method for single speed
changers, it is critical to use the same method (manual or
tachometer) on both input and output shafts.
Table 4-9 is a list of the gearbox options. Depending on
the known components, more options appear for the
details.
