810
Users Manual
3-8
gbk07.eps
Figure 3-3. Sensor Setup and Connection
Sensor Care and Handling
W Caution
• To prevent damage to the piezoelectric
element inside the Sensor, do not drop.
A faulty Sensor significantly affects the
diagnostic quality.
• Do not pull or force the cable while
attaching or removing the Sensor.
• Allow the Sensor 10 seconds to warm-up
before data collection.
• Make sure that all cables are free from
any rotating parts of the machine.
• Always disconnect the Sensor cable
from the Tester when not in use.
• Always place the Sensor in the softcase
pouch when not in use.
