Fluke 810 - Start the Tester

810
Users Manual
3-6
Table 3-3. Accessory Connectors
Item Connector Description
 Tachometer Connects the Tachometer
 USB
Connects the Tester to the PC
using a USB cable
 Sensor
Optional connector for single
axis Sensor
 Sensor Connects the triaxial Sensor
Start the Tester
Note
• Before using the Tester for the first time,
charge the battery for at least three hours.
For charging procedure, see “Battery.”
• Before using the Tester, make sure that
there is sufficient battery charge and free
memory.
Push  to turn on the Tester. At power up, the Tester
displays the remaining memory and the battery status.
Push  and hold two seconds to turn off the Tester
The battery status icon U and the set date and time
appear at the top of the display.
