810
Users Manual
4-8
RPM Entry
When an RPM value has to be entered, the RPM entry
screen opens.
1. Use the Tachometer to measure the RPM. See
“Tachometer Setup” to set up the Tachometer
and measure the RPM. After you set the RPM
value, the Tester goes back to the Machine
Setup wizard.
Or, you can manually enter the RPM value as
follows:
2. Push Manual Entry. The Tester displays a
numeric keyboard.
3. To select a character, use the Dial to highlight
the value. Or, use Move Cursor to highlight the
value.
4. Push the Dial to select the value.
5. To delete a character, use Delete Character.
6. Push Done to go back to the Machine Setup
wizard.
Coupling Information
If the machine consists of a driven component coupled
with a motor, select No to the previous option. Options for
the closed coupled machine appear based on the
selection you make.
