Operation
Machine Setup
4
4-15
Table 4-9. Gearbox Options for the Transmission
Selection Option Action Option Description
Roller
Gearbox
bearing type
Journal
Select the gearbox
bearing type
1
2
Number of
speed
changes
3
Scroll and select the
number of speed
changes.
---
Shaft
speeds
Push Keyboard to access the numeric keyboard.
Enter the shaft speeds in their respective fields.
Gear ratios
Push Keyboard to access the numeric keyboard.
Enter the gear ratios in their respective fields.
What is
known?
Gear tooth
count
Depending on the
known information,
scroll and select that
option.
Numeric
keyboard entry
Push Keyboard to access the numeric keyboard.
Enter the number of gear teeth in their respective
fields.
