Chapter 3 The Cradle
168
You can wire one alarm device for High alarm level (AL – H
terminal) and another alarm device for the low alarm level (AL – L
terminal), or you can connect the same device to both terminals so
it will operate whenever any of the alarm level is exceeded.
If you want to operate an alarm device that consumes more than
30VDC, 1A or an AC alarm device. You will have to use a relay.
External power: Connection to an external 12VDC power supply
(i.e. vehicle battery).
To connect to the screw terminals:
1. Unfasten the antenna screw at the top back of
the cradle.
2. Remove the antenna.
