Fronius Datamanager 2.0 User Manual

22
No. Function
(1) IP switch
For changing the IP address:
A Specified IP address and opening the WLAN Access Point
Fronius Datamanager 2.0 uses fixed IP address 169.254.0.180 for a direct con-
nection to a PC via LAN.
If the IP switch is set to position A, an Access Point for a direct WLAN connec-
tion to Fronius Datamanager 2.0 is also opened.
Access data for this Access Point:
Network name: FRONIUS_240.XXXXXX
Key: 12345678
Fronius Datamanager 2.0 can be accessed:
- via DNS name "http://datamanager"
- via IP address 169.254.0.180 for the LAN interface
- via IP address 192.168.250.181 for the WLAN Access Point
B Assigned IP address
Fronius Datamanager 2.0 works with an assigned IP address dynamic host
configuration protocol (DHCP)
The IP address can be set on the Fronius Datamanager 2.0 website.
In the case of Fronius Datamanager 2.0 plug-in cards, the IP switch is located
underneath the LEDs and is separate in the case of the Fronius Datamanager
Box 2.0.
(2) WLAN LED
- Flashes green: Fronius Datamanager 2.0 is in service mode
(IP switch on the Fronius Datamanager 2.0 plug-in card is set to position A
or service mode was activated via the inverter display, the WLAN Access
Point is opened)
- Lights up green: There is an existing WLAN connection
- Alternately flashes green/red: The length of time for which the WLAN Ac-
cess Point is open after activation (1 hour) has been exceeded
- Lights up red: There is no existing WLAN connection
- Flashes red: Faulty WLAN connection
- Does not light up: Fronius Datamanager 2.0 is in slave mode
(3) Fronius Solar.web connection LED
- Lights up green: There is an existing connection to Fronius Solar.web
- Lights up red: There is no existing connection to Fronius Solar.web, but
one is required
- Does not light up: No connection to Fronius Solar.web is required
(4) Supply LED
- Lights up green: Sufficient power supply from Fronius Solar Net; Fronius
Datamanager 2.0 is operational
- Does not light up: No power or insufficient power supply from Fronius Solar
Net – an external power supply is required
or
Fronius Datamanager 2.0 is in slave mode
- Flashes red: During an update process
IMPORTANT! Do not interrupt the power supply during an update process.
- Lights up red: Update process failed

Fronius Datamanager 2.0 Specifications

General

Monitoring Platform	Fronius Solar.web
Communication Interfaces	Ethernet
Protocols	Modbus TCP
Data Logging	Integrated data logger
Web Interface	Yes
Compatibility	Fronius inverters
Power Supply	Via inverter
Mounting	Wall mounting
