Fronius Datamanager 2.0 User Manual

90
(4) First activate power factor cos phi,
then enter the desired power factor and select "ind" or "cap"
ind = inductive
cap = capacitive
(5) UC Output (feedback output)
When the rule is activated, the I/O 0 output will be activated (e.g., for operating a
signal device)
(6) Excluded inverters
Enter the numbers of inverters here that are to be excluded from control. Separate
multiple inverters with commas.
(7) Delete/Add a Rule
+ = add a new rule
- = delete selected rule
(8) Legend for use of colors
(9) Click "Import" button
to import rules in *.fpc format
The function of the "Import" button depends on the browser used, e.g., Firefox and
Google Chrome support the function.
(10) Click "Export" button
to save the rules separately in *.fpc format
(11) "Apply/Save" button
(12) "Cancel/Discard entries" button
Connection Ex-
ample
(1) Ripple control signal receiver with 3 relays for effective power limitation
(2) Ripple control signal receiver with 3 relays for power factor limitation
(3) I/Os on Fronius Datamanager 2.0
(4) Loads (e.g., signal light, signal relay)
NOTE! The print function of the web browser can be used to save the UC Editor
settings as a PDF or print them out (e.g., as a commissioning report).

Fronius Datamanager 2.0 Specifications

General

Monitoring Platform	Fronius Solar.web
Communication Interfaces	Ethernet
Protocols	Modbus TCP
Data Logging	Integrated data logger
Web Interface	Yes
Compatibility	Fronius inverters
Power Supply	Via inverter
Mounting	Wall mounting
