Fronius Primo 3.0-1 Service Manual

125
EN
Pull off the sealing plug (6)
Remove the left external fan from the
fan holder
by pushing the two locking devices (7)
outwards
IMPORTANT! Observe the direction of the
air flow when installing the new fan.
The fan must blow air towards the centre of
the device.
Insert the new external fan into the fan
holder
by attaching it at the top and pushing
downwards
Feed in the fan cable
Fit the sealing plug (6)
IMPORTANT! The sealing plug must not le-
ak.
(6)
6
(7)
7
7
7
8
(6)
9
10

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
