Fronius Symo GEN24 10.0 User Manual

K3 - modular relay
Test standard IEC 60947-4-1
Examples of contact-
ors and relays
Finder 22.23.9.012.4000 / Schrack relay RT424012
(bracket RT17017, relay base RT78725)
K4 and K5 - installation contactor
Number of NC con-
tacts
2 (25 A)
Coil voltage 230 V AC (2P)
Rated frequency 50/60 Hz
Coil fuse 6 A
Min. short circuit cur-
rent
3 kA (make contacts)
Test standard IEC 60947-4-1
Examples of contact-
ors and relays
ISKRA IKA225-02
158

Fronius Symo GEN24 10.0 Specifications

General

Model	Fronius Symo GEN24 10.0
Category	Inverter
AC nominal output	10.0 kW
AC grid frequency	50 Hz / 60 Hz
THD	< 3 %
Number of MPP trackers	2
Protection class	IP66
AC Nominal Voltage	230 V / 400 V
Operating Temperature Range	-25°C to +60°C
Max. apparent AC power	10, 000 VA
AC nominal voltage range	230 V
DC connection	4x DC+ and 4x DC- screw terminals
Maximum AC Power	10000 VA
Maximum DC Power	15 kW
AC Voltage Range	180 - 280 V
Cooling	Active cooling
Warranty	5 years
