Fronius Symo GEN24 10.0 User Manual

Technical data
Fronius Symo
GEN24 6.0 / 6.0
Plus
DC input data
MPP voltage range
(at rated power)
174 - 800 V
Max. connected load (P
PV max
)
Total
PV 1
PV 2
9000 Wp
7500 Wp
6500 Wp
Max. processable PV power
Total
PV 1
PV 2
6220 Wp
6220 Wp
6000 Wp
Max. input voltage
at 1000 W/m² / -10 °C in an open cir-
cuit
1000 V
Feed-in start-up input voltage in grid
operation
5)
80 V
Max. input current
PV 1
PV 2
25.0 A
12.5 A
Max. short circuit current of PV mod-
ules (I
SC PV
)
PV 1
PV 2
37.5 A
18.75 A
Max. short circuit current
(I
SC PV1
+ I
SC PV2
= I
SC max
)
Total
56.25 A
Max. inverter backfeed current to the
array
3)
37.5 A
Number of inputs - PV 1 2
Number of inputs - PV 2 1
Max. capacity of the PV generator
against earth
1200 nF
Insulation resistance test limit value
between PV generator and earth (on
delivery)
10)
100 kΩ
Adjustable range of insulation resist-
ance test between PV generator and
earth
9)
10 - 10000 kΩ
Limit value and tripping time of the
sudden residual current monitoring
(on delivery)
30 / 300 mA / ms
60 / 150 mA / ms
90 / 40 mA / ms
Limit value and tripping time of the
continuous residual current monitor-
ing (on delivery)
300 / 300 mA / ms
160

Fronius Symo GEN24 10.0 Specifications

General

Model	Fronius Symo GEN24 10.0
Category	Inverter
AC nominal output	10.0 kW
AC grid frequency	50 Hz / 60 Hz
THD	< 3 %
Number of MPP trackers	2
Protection class	IP66
AC Nominal Voltage	230 V / 400 V
Operating Temperature Range	-25°C to +60°C
Max. apparent AC power	10, 000 VA
AC nominal voltage range	230 V
DC connection	4x DC+ and 4x DC- screw terminals
Maximum AC Power	10000 VA
Maximum DC Power	15 kW
AC Voltage Range	180 - 280 V
Cooling	Active cooling
Warranty	5 years
