Fronius Symo GEN24 10.0 User Manual

Status codes and remedy
Display Status codes are displayed on the user interface of the inverter in the "System" →
"Event Log" menu or in the user menu under "Notifications" or in Fronius Sol-
ar.web*.
* with corresponding configuration, see chapter Fronius Solar.web on page
17.
Status Codes
1030 - WSD Open (operation LED: lights up red)
A device connected in the WSD chain has interrupted the signal line
(e.g. a surge protective device) or the bypass ex works has been re-
moved and no trigger device has been installed.
If the SPD surge protective device is triggered, the inverter must be
repaired by an authorised specialist.
Install the bypass ex works or a trigger device.
Set the WSD (wired shutdown) switch to position 1 (WSD primary
device).
WARNING!
Danger due to work that has been carried out incorrectly.
This can result in serious injury and damage to property.
▶
Installing and connecting a surge protective device (SPD) must only be car-
ried out by service personnel trained by Fronius and only within the scope of
the respective technical regulations.
▶
Follow the safety rules.
Cause:
Remedy:
OR:
OR:
159
EN

Fronius Symo GEN24 10.0 Specifications

General

Model	Fronius Symo GEN24 10.0
Category	Inverter
AC nominal output	10.0 kW
AC grid frequency	50 Hz / 60 Hz
THD	< 3 %
Number of MPP trackers	2
Protection class	IP66
AC Nominal Voltage	230 V / 400 V
Operating Temperature Range	-25°C to +60°C
Max. apparent AC power	10, 000 VA
AC nominal voltage range	230 V
DC connection	4x DC+ and 4x DC- screw terminals
Maximum AC Power	10000 VA
Maximum DC Power	15 kW
AC Voltage Range	180 - 280 V
Cooling	Active cooling
Warranty	5 years
