6.4 Selecting Options
6-27
Chap. 6 SELECTING PERIPHERAL EQUIPMENT
Table 6.11 AC Reactor (ACR)
AC reactor (ACR)
Reactance (mΩ/phase)
Power
supply
voltage
Applicable
motor
rating
(kW)
Applicable
motor
rating
(HP)
Inverter type
Type
Rated current
(A)
50 Hz 60 Hz
Generated loss
(W)
0.1 1/8 FRN0001C2S-2 2.5
0.2 1/4 FRN0002C2S-2 5
0.4 1/2
FRN0004C2S-2
ACR2-0.4A 3 917 1100
10
0.75 1
FRN0006C2S-2
ACR2-0.75A 5 493 592 12
1.5 2
FRN0010C2S-2
ACR2-1.5A 8 295 354 14
2.2 3
FRN0012C2S-2
ACR2-2.2A 11 213 256 16
3.7 5
FRN0020C2S-2
ACR2-3.7A 17 128 153 23
5.5 7.5
FRN0025C2S-2
ACR2-5.5A 25 87.7 105 27
7.5 10
FRN0033C2S-2
ACR2-7.5A 33 65 78 30
11 15
FRN0047C2S-2
ACR2-11A 46 45.5 54.7 37
Three-
phase
200 V
15 20
FRN0060C2S-2
ACR2-15A 59 34.8 41.8 43
0.4 1/2 FRN0002C2-4 5
0.75 1 FRN0004C2-4
ACR4-0.75A 2.5 1920 2300
10
1.5 2 FRN0005C2-4 ACR4-1.5A 3.7 1160 1390 11
2.2 3 FRN0007C2-4 ACR4-2.2A 5.5 851 1020 14
3.7/4.0 5 FRN0011C2-4 ACR4-3.7A 9 512 615 17
5.5 7.5 FRN0013C2-4 ACR4-5.5A 13 349 418 22
7.5 10 FRN0018C2-4 ACR4-7.5A 18 256 307 27
11 15 FRN0024C2-4 ACR4-11A 24 183 219 40
Three-
phase
400 V
15 20 FRN0030C2-4 ACR4-15A 30 139 167 46
0.1 1/8 FRN0001C2-7 5
0.2 1/4 FRN0002C2-7
ACR2-0.4A 3 917 1100
10
0.4 1/2 FRN0004C2-7 ACR2-0.75A 5 493 592 12
0.75 1 FRN0006C2-7 ACR2-1.5A 8 295 354 14
1.5 2 FRN0010C2-7 ACR2-2.2A 11 213 256 16
Single-
phase
200 V
2.2 3 FRN0012C2-7 ACR2-3.7A 17 128 153 23
0.1 1/8 FRN0001C2S-6U ACR2-0.4A 3 917 1100 2.5
0.2 1/4 FRN0002C2S-6U ACR2-0.75A 5 493 592 12
0.4 1/2 FRN0003C2S-6U ACR2-1.5A 8 295 354 14
Single-
phase
100 V
0.75 1 FRN0005C2S-6U ACR2-3.7A 17 128 153 23
Note 1: Generated losses listed in the above table are approximate values that are calculated according to the following
conditions:
- The power source is 3-phase 200 V/400 V 50 Hz with 0% interphase voltage unbalance ratio.
- The power source capacity uses the larger of either 500 kVA or 10 times the rated capacity of the inverter.
- The motor is a 4-pole standard model at full load (100%).
Note 2: A box () in the above table replaces A, C, E, or U depending on shipping destination.
Note 3: A box (
■) in the above table replaces S (Basic type) or E (EMC filter built-in type) depending on the enclosure.
