Chap. 8 SPECIFICATIONS
8.2 Semi-standard Models
8.2.1 EMC filter built-in type in three-phase 400 V series
FRN_ _ _ _C2E-4, where  = C, E
Item Specifications
Type (FRN_ _ _ _C2E-4)
( = C or E)
0002 0004 0005 0007 0011 0013 0018 0024 0030
Nominal applied motor (kW) *
1
0.4 0.75 1.5 2.2
3.7 (  =C)
4.0 (
 =E)
5.5 7.5 11 15
Nominal applied motor (HP) *
1
1/2 1 2 3 5 7.5 10 15 20
Rated capacity (kVA) *
2
1.3 2.3 3.2 4.8 8.0 9.9 13 18 22
Rated voltage (V) *
3
Three-phase, 380 to 480 V (with AVR function)
Rated current (A) *
4
1.8
(1.5)
3.1
(2.5)
4.3
(3.7)
6.3
(5.5)
10.5
(9.0)
13.0 18.0 24.0 30.0
Overload capability
150% of rated current for 1 min.
150% of rated current for 1 min or 200% of rated
current for 0.5 s (for the rated current given in
parentheses)
150% of rated current for 1 min or
200% of rated current for 0.5 s
Output Ratings
Rated frequency (Hz) 50 / 60 Hz
Phases, voltage, frequency Three-phase, 380 to 480 V, 50/60 Hz
Voltage and frequency
variations
Voltage: +10 to -15% (Interphase voltage unbalance: 2 % or less*
5
),
Frequency: +5 to -5%
(w/ DCR) 0.85 1.6 3.0 4.4 7.3 10.6 14.4 21.1 28.8
Rated current
(A) *
6
(w/o DCR) 1.7 3.1 5.9 8.2 13.0 17.3 23.2 33.0 43.8
Input Ratings
Required power supply
capacity (kVA) *
7
0.6 1.1 2.0 2.9 4.9 7.4 10 15 20
Braking torque (%) *
8
100 50 30 20
DC braking
Starting frequency*
9
: 0.0 to 60.0 Hz, Braking time: 0.0 to 30.0 s,
Braking level: 0 to 100%
Braking
Braking transistor Built-in
Applicable safety standards UL508C, EN61800-5-1: 2007
Applicable EMC standards
(EN61800-3:2004 +A1:2012)
Immunity :
Second Environment (Industrial)
Emission : Category C2
Immunity :
Second Environment (Industrial)
Emission : Category C3
Enclosure IP20 (IEC 60529:1989), UL open type (UL50)
Cooling method Natural cooling Fan cooling
Mass (kg) 1.5 1.6 3.0 3.1 3.2 4.6 4.6 6.7 6.7
*1 Fuji 4-pole standard motors.
*2 Assuming the rated output voltage as 440 V for three-phase 400 V series.
*3 Output voltages cannot exceed the power supply voltage.
*4 The load shall be reduced so that the continuous operating current is the rated current in parentheses or less if the
carrier frequency is set to 3 kHz or above or the ambient temperature exceeds 40°C (104°F).
*5
2004):3-61800IECto(Refer67
(V)voltageaveragephase-Three
(V)eMin.voltag-(V)voltageMax.
(%)unbalancevoltageInterphase ×=
If this value is 2 to 3%, use an optional AC Reactor (ACR).
*6 Estimated value to apply when the inverter is connected to the power supply of 500 kVA (inverter capacity x 10
when the inverter capacity exceeds 50 kVA) and %X = 5%.
*7 Obtained when a DC Reactor (DCR) is used.
*8 Average braking torque when a motor of no load decelerates from 60 Hz. (It varies with the efficiency of the
motor.)
*9 Effective function only in induction motor drive.
Note: A box () in the above table replaces A, C, E, or U depending on the shipping destination.
C: China, E: EC
