3.3 Programming Mode
3-9
Chap. 3 OPERATION USING THE KEYPAD
Limiting menus to be displayed
The menu-driven system has a limiter function (specified by function code E52) that limits menus to
be displayed for the purpose of simple operation. The factory default is to display Menu #1 "Data
setting" only, allowing no switching to any other menu.
Function Code E52 – Menu Display Mode for Keypad
Function code data (E52) Menus selectable
0: Function code data setting mode Menu #1 "Data setting" (factory default)
1: Function code data check mode Menu #2 "Data checking"
2: Full-menu mode Menu #1 through #6 (#7*)
* Menu #7 appears only when the remote keypad (option) is mounted.
If the full-menu mode is selected, pressing the / keys will cycle through menus. With
the key, you may select the desired menu. Once all of the menus have been cycle
through, the display will return to the first menu.
3.3.1 Setting the function codes--"Data Setting"
Menu #1 "Data setting" in Programming mode allows you to set function codes for making the
inverter functions match your needs.
The table below lists the function codes available in the FRENIC-Mini. The function codes are
displayed on the LED monitor on the keypad as shown below.
Table 3.4 List of FRENIC-Mini Function Codes
Function code group Function code Function Description
F codes
(Fundamental functions)
F00 to F51 Basic functions To be used for basic motor running.
E codes
(Extension terminal
functions)
E01 to E99 Terminal functions
To be used to select the functions of
the control circuit terminals.
To be used to set functions related to
the LED monitor display.
C codes
(Control functions of
frequency)
C01 to C52 Control functions
To be used to set application functions
related to frequency settings.
P codes
(Motor parameters)
P02 to P99 Motor 1 parameters
To be used to set specific parameters
for the motor capacity, etc.
H codes
(High performance
functions)
H03 to H98
High level
functions
To be used for high added value
functions and complicated control,
etc.
A codes
(Alternative motor
functions)
A01 to A52 Motor 2 parameters
To be used to set specific parameters
for the motor capacity, etc.
J codes
(Application functions)
J01 to J72
Application
functions
To be used for PID control and brake
signals.
y codes
(Link functions)
y01 to y99 Link functions To be used for communications.
Refer to Chapter 9 "FUNCTION CODES" for details on the function codes.
Function code group
ID number in each function code group
