8.4 Terminal Specifications
8-23
Chap. 8 SPECIFICATIONS
Recommended ferrule terminals
Manufacturer: WAGO.
Type (216-)
w/ isolation collar w/o isolation collar
Screw size Wire size
Short type Long type Short type Long type
AWG24 (0.25 mm
2
) 321 301 151 131
AWG22 (0.34 mm
2
) 322 302 152 132
AWG20 (0.50 mm
2
) 221 201 121 101
M2
M2.5
AWG18 (0.75 mm
2
) 222 202 122 102
The wire strip length to be inserted into a ferrule terminal is 5.0 mm (0.20 inch) for the short type and 8.0 mm (0.31
inch) for the long type. The recommended crimping tool is Variocrimp 4, Model No. 206-204.
